AXI 2820/14 Cyclone KV860

AXI 2820/14 Cyclone KV860

AXI model motors

3EL105704

Pas de stock

€ 145,99 € 120,65 TVA excl.

Powering LiXX cells	3 - 4
RPM/V [ot./min/V]	860
Turn count	14
Internal resistance [mOhm]	78
Open-circuit current [A]	1.6
Max. efficiency [%]	88
Max. efficiency current (η>75%) [A]	15 - 30
Max. peak current (60 s) [A]	40
Max. power [W]	530
Diameter [mm]	40
Length [mm]	69
Shaft diameter [mm]	5
Weight [g]	197
Poles count	14
Timing [°]	15 - 25
ESC [A]	40 - 50
Weight of glider (up-to) [g]	2400

General Info

Brand: AXI model motors

Barcode: 8595247303257,00

Motor - Specs

Motor - Input Voltage Range (V): 3S - 4S Li-Po

Motor - KV (Rpm/V): 860,00

Motor - Poles: 14-Pole

Motor - Timing: 15-25

Motor - Turns (T): 14,00

Motor - Dimensions

Motor - Dia. ø (mm): 40,00

Motor - Length (mm): 69,00

Motor - Shaft Dia. ø (mm): 5.0 mm

Motor - Weight (g): 197,00
