General Info
- Brand
-
Jeti
- Item Nr
-
J-DPS-40
- Barcode
-
8595245909017
ESC - Specs
- ESC- Input Voltage Range (V)
-
2S - 12S Li-Po
- ESC - Current - Cont. (A)
-
90
- ESC - Current - Peak (A)
-
90
- ESC - BEC - Voltage (V)
-
Adj. 5.0V - 8V
- ESC - BEC - Cont. (A)
-
8
- ESC - BEC - Peak (A)
-
15
- ESC - Protection
-
No
- ESC - Cooling Fan
-
No
- ESC - Case Material
-
Aluminium + Plastic
ESC - Programming
- ESC - Firmware Update
-
Supported
- ESC - Telemetrie Aux.
-
Yes, telemetry aux.
- ESC - Data Logging
-
Yes, Real Time Data - Max Values
- ESC - Real-Time Data
-
- RPM (T/min)
- Capacity (mAh)
- Current (A)
- Temperature (°)
- Voltage (V)
- ESC Status
- ESC - Governor Mode
-
Supported
ESC - Dimensions
- ESC - Length (mm)
-
36
- ESC - Width (mm)
-
20
- ESC - Thickness (mm)
-
109
- ESC - Wires (AWG) - Battery
-
14 AWG
- ESC - Wires (AWG) - Motor
-
14 AWG
- ESC - Connector - Battery
-
None
- ESC - Weight (g)
-
140
ESC - Application
- ESC - Application
-
Airplanes - Helicopters
- ESC - Motor Type
-
In-Runner & Out-Runner Sensored - Sensorless Motors
- ESC - Motor Control
-
Forward - Brake - Reverse
- ESC - Level
-
Hobby - Sport - High-End
